The Schneider Electric LC1G150KUEN is a TeSys Giga series high-power contactor engineered for demanding industrial motor control and power switching applications. Featuring a 3-pole (3NO) configuration and AC-3 operational current rating of 150A at ≤440V, the contactor is designed for reliable switching of high-power motors and industrial loads. It incorporates a low-consumption wide-band electronic coil supporting 100–250V AC/DC control voltage for flexible installation in various automation systems. The TeSys Giga platform includes advanced reliability features such as integrated auxiliary contacts, contact wear diagnostics, and high mechanical endurance for severe-duty industrial environments. Designed for panel mounting with front-access power connections, the LC1G150KUEN is suitable for MCC panels, industrial automation systems, motor starters, HVAC systems, and heavy-duty electrical switching applications.
Specifications
| Specification | Value |
| Product Name | Schneider Electric LC1G150KUEN |
| Brand | Schneider Electric |
| Series | TeSys Giga |
| Main Category | Electrical & Lighting |
| Sub-Category | Automations |
| Product Type | High Power Contactor |
| Pole Configuration | 3 Pole (3NO) |
| AC-3 Current Rating | 150A |
| Rated Operational Voltage | ≤ 440V |
| Motor Power Rating | 90kW @ 440V |
| Coil Voltage | 100–250V AC/DC |
| Coil Type | Wide Band Electronic Coil |
| Auxiliary Contacts | 1NO + 1NC Integrated |
| Mounting Type | Panel Mount |
| Terminal Type | Bolt Connection |
| Mechanical Durability | Up to 8 Million Operations |
| Operating Temperature | -25°C to +60°C |
| Protection Class | IP2X (with terminal covers) |
| Application | Motor Control & Industrial Automation |
| Standards | IEC / CE / UL |
| Product Reference | LC1G150KUEN |
