The Eaton DILM25-10 (Part No. 277136) is a heavy-duty industrial motor control contactor from Eaton’s Moeller DILM series, engineered for reliable switching of three-phase motors and industrial power circuits. Featuring a 3-pole main contact configuration and an integrated 1 Normally Open auxiliary contact, the contactor is suitable for motor starters, pumps, compressors, HVAC systems, conveyors, packaging machinery, and factory automation equipment. The unit operates using a 24V AC 50/60Hz control coil and provides a 25A AC-3 operational rating for demanding motor control applications. Designed according to IEC industrial standards, the DILM25-10 offers compact dimensions, DIN rail or panel mounting capability, high electrical endurance, and compatibility with Eaton overload relays and motor starter assemblies. Its robust screw terminal construction ensures secure wiring and dependable long-term performance in industrial environments.
Product Specifications
| Specification | Details |
| Brand | Eaton |
| Series | DILM Series |
| Model | DILM25-10 |
| Part Number | 277136 |
| Product Type | Power Contactor |
| Category | Motor Control Contactor |
| Main Contacts | 3 Pole (3NO) |
| Auxiliary Contacts | 1 NO Built-In |
| Rated Operational Current (AC-3) | 25 A |
| Coil Voltage | 24V AC |
| Coil Frequency | 50/60 Hz |
| Motor Rating @ 400V AC-3 | 11 kW |
| Rated Operational Voltage | Up to 690V AC |
| Rated Insulation Voltage (Ui) | 690V |
| Utilization Category | AC-1, AC-3 |
| Connection Type | Screw Terminal |
| Mounting Type | DIN Rail / Panel Mount |
| Mechanical Life | High Industrial Duty |
| Electrical Life | Industrial Grade |
| Protection Class | IP20 |
| Application | Motor Switching & Industrial Automation |
| Suitable For | Pumps, Compressors, Conveyors, HVAC Systems |
| Standards | IEC Industrial Control Standards |
| Country of Brand Origin | Germany |
