The Eaton DILA-XHI22 Auxiliary Contact Block (Part No. 276426) is an industrial control accessory engineered to expand the auxiliary contact capacity of Eaton DILA and DILM contactors. Featuring a 2NO + 2NC contact arrangement, the module enables additional control logic, PLC interfacing, interlocking circuits, status indication, alarm functions, and automation signaling applications. The unit mounts directly onto the front of compatible contactors through a snap-on installation mechanism, minimizing panel space requirements while increasing system functionality. Designed according to IEC industrial control standards, the DILA-XHI22 offers reliable switching performance, durable contact construction, and compatibility with motor control centers, machinery panels, manufacturing systems, conveyors, pumps, compressors, and factory automation equipment.
Product Specifications
| Specification | Details |
| Brand | Eaton |
| Series | DILA / DILM Series |
| Model | DILA-XHI22 |
| Part Number | 276426 |
| Product Type | Auxiliary Contact Block |
| Contact Configuration | 2NO + 2NC |
| Number of Contacts | 4 Auxiliary Contacts |
| Mounting Position | Front Mounted |
| Mounting Method | Snap-On |
| Compatible Contactors | Eaton DILA & DILM Series |
| Contact Type | Auxiliary Switching Contacts |
| Rated Insulation Voltage (Ui) | 690 V |
| Rated Operational Voltage | Up to 690 V AC |
| Connection Type | Screw Terminal |
| Utilization Category | IEC Industrial Control Applications |
| Mechanical Life | High Durability Industrial Design |
| Electrical Life | Industrial Duty Rated |
| Protection Class | IP20 |
| Application | Interlocking, Signaling & Control Circuits |
| Suitable For | Contactors, Motor Starters, PLC Panels |
| Industrial Usage | Automation, Manufacturing, Process Control |
| Standards Compliance | IEC 60947 |
| Country of Brand Origin | Germany |
