The SMC CUJB8-10S is a compact miniature free-mount pneumatic cylinder from the CUJ series engineered for high-performance linear motion control in space-constrained automation systems. Designed with a lightweight compact body and lateral mounting capability, the cylinder provides reliable single-acting spring-return operation with an 8mm bore and 10mm stroke. The miniature design allows installation from multiple directions while reducing overall machine footprint. Manufactured using durable aluminum alloy construction, the CUJB8-10S delivers stable pneumatic actuation performance for industrial automation, pick-and-place systems, compact machinery, and precision motion applications. The cylinder supports operating pressures up to 0.7 MPa and is suitable for continuous-duty industrial environments requiring compact and dependable pneumatic motion control.
Specifications
| Specification | Value |
| Product Name | SMC CUJB8-10S |
| Brand | SMC |
| Series | CUJ Series |
| Main Category | Pneumatics |
| Sub-Category | Pneumatic Cylinders |
| Product Type | Mini Free Mount Pneumatic Cylinder |
| Bore Size | 8 mm |
| Stroke Length | 10 mm |
| Action Type | Single Acting Spring Return |
| Mounting Type | Lateral / Free Mount |
| Cushioning Type | Rubber Bumper |
| Body Material | Aluminium Alloy |
| Rod Type | Single Rod |
| Rod Thread | Female Thread |
| Port Size | M3 |
| Maximum Operating Pressure | 0.7 MPa |
| Minimum Operating Pressure | 0.2 MPa |
| Piston Speed | 50 – 500 mm/s |
| Operating Temperature | -10°C to +70°C |
| Fluid Medium | Compressed Air |
| Application | Industrial Automation |
| Usage | Compact Motion Control Systems |
| Delivery Terms | 2–3 Weeks |
