PVC Conveyor Belt

https://www.mventus.com/web/image/product.template/24796/image_1920?unique=21b205c
PVC Conveyor Belt is a commonly used industrial conveyor belt material, which is widely used in logistics, food processing, packaging, electronics, agriculture and other industries.Made of high quality polyvinyl chloride (PVC) material with excellent abrasion, tear, oil and chemical resistance, PVC conveyor belts are the preferred choice for many industrial conveyor solutions due to their cost-effective, lightweight and easy-to-install nature and good conveying performance.
Read More

Not Available For Sale


This combination does not exist.

Contact Us
SKU:
Product Code:



  • Max-Width:
    • Max-Width: The maximum width of PVC conveyor belt can be up to 3400MM, depending on the thickness.The maximum width of conveyor belt with thickness of 2-3MM is 3200MM, and the maximum width of conveyor belt with thickness of more than 4MM can reach 3400MM.
  • Material & Structure:
    • Cover Material: Optional materials include PVC (Polyvinyl Chloride), PE (Polyolefin), PU (Polyurethane), TPE (Polyester) and SI (Silicone) to meet different requirements for durability, flexibility and chemical resistance.
    • Fabric Layers: Depending on the usage requirements, PVC conveyor belts can be customized with different layers of fabric construction to enhance its strength and durability.
  • Fabric Types:
    • A wide range of fabric types are available including:
      • Non-Lateral Stability: polyester gauze, polyester fabrics.
      • Lateral stability: polyester fabrics (e.g. 100N/mm and 80N/mm strength), high strength polyester fabrics.
      • Composite fabrics: cotton/polyester composite fabrics, cotton/polyester yarn composite fabrics.
      • Special function fabrics: low noise fabrics, cotton fabrics, etc., adapting to different industrial application scenarios.
  • Surface Coating Colors:
    • PVC conveyor belts are available in a wide range of color options such as clear, green, white, black, grey, red, beige, blue-green, blue and orange to meet different visual and functional needs.
  • Top-covered/bottom-covered profiles:
    • Multiple combinations of surface coatings and patterns are available to ensure optimum friction and stability during material handling.Common options include:
      • Normal thickness, medium thickness and extra thick coatings.
      • Various patterns such as diamond patterns and fabric patterns to suit different working environments and needs.
  • Surface Pattern Options:
    • A wide variety of surface patterns are available to enhance the efficiency and reliability of material handling, including matte, diamond, high friction, dot, serrated, golf ball, mesh, pinstripe, antistatic, large chevron, raised tooth, twill, corrugated, and more.
  • Applicable industries and uses:
    • Logistics and warehousing: for efficient conveying of parcels and goods, providing excellent wear resistance and long-term reliability.
    • Food Processing: Meets food grade requirements, can be used in the production and conveying process of bread, pastry, candy and other foodstuffs to ensure hygiene and material safety.
    • Packaging industry: It is suitable for all kinds of packaging production lines, preventing materials from sliding or shifting and ensuring the stable operation of the production line.
    • Electronic manufacturing: used in the transportation of electronic parts and products, with anti-static properties, reduce static electricity accumulation.
    • Agriculture: in the process of sorting and conveying of agricultural products, to prevent material damage and pollution, suitable for vegetables, fruits, grains and so on.
  • Product Advantage:
    • HIGH DURABILITY AND VERSATILITY: Able to be customized according to specific needs, offering a wide range of colors, materials, structures and pattern combinations to adapt to different industrial applications.
    • Easy to clean and maintain: the material has a smooth, chemical-resistant surface that is easy to clean, reducing maintenance costs and downtime.
    • Versatility: Suitable for a wide range of industrial applications, from light food processing to heavy-duty logistics and transportation, providing reliable and efficient conveying solutions.
