The 0–6 Bar Pressure Gauge with 100 mm dial is a precision industrial measuring instrument designed for accurate monitoring of gas and liquid pressure in industrial systems. Constructed with a durable stainless steel case and brass threaded wetted connection, the gauge offers reliable performance, corrosion resistance, and long operational life in demanding industrial environments. The bottom-entry 1/2" NPT connection enables easy inline installation on pipelines, compressors, pumps, hydraulic systems, air receivers, and process equipment. Featuring a clear 100 mm analogue dial with Bourdon tube sensing mechanism, the gauge provides stable and accurate pressure indication for industrial automation, utilities, HVAC systems, pneumatic applications, and water systems. The robust construction ensures resistance to vibration, pressure fluctuations, and continuous-duty operation.
Product Specifications
| Specification | Details |
| Product Type | Pressure Gauge |
| Pressure Range | 0 – 6 Bar |
| Dial Diameter | 100 mm |
| Case Material | Stainless Steel |
| Connection Material | Brass |
| Connection Type | Bottom Connection |
| Thread Size | 1/2" NPT |
| Measuring Principle | Bourdon Tube |
| Mounting Type | Direct Bottom Mount |
| Display Type | Analogue Dial |
| Accuracy Class | Class 1.6 |
| Window Material | Glass / Polycarbonate |
| Wetted Parts | Brass Alloy |
| Media Compatibility | Air, Water, Oil, Non-Corrosive Fluids |
| Operating Temperature | Industrial Standard |
| Application | Pressure Measurement |
| Suitable For | Compressors, Pumps, Pneumatic Systems |
| Installation | Inline Pipeline Mounting |
| Protection | Industrial Duty Construction |
| Country of Manufacture | Industrial Grade Imported / India |
