The 3PC Body Ball Valve Butt Welded 3 Inch SS316 Full Port 1000 PSI is a heavy-duty industrial isolation valve engineered for reliable flow control in high-pressure process systems. Manufactured from corrosion-resistant SS316 stainless steel, the valve features a robust three-piece body construction that enables easy maintenance and inline servicing without removing the complete valve assembly from the pipeline. The full port design allows unrestricted flow with minimal pressure drop, making it ideal for oil, gas, water, steam, chemical, and industrial process applications. The butt weld end connections provide strong leak-proof permanent installation suitable for high-pressure piping systems. Designed with PTFE seats and blow-out proof stem construction, the valve ensures smooth quarter-turn operation, excellent sealing performance, and long operational life in demanding industrial environments.
Product Specifications
| Specification | Details |
| Product Type | 3 Piece Ball Valve |
| Valve Type | Full Port Ball Valve |
| Body Design | 3PC Body Construction |
| Valve Size | 3 Inch |
| End Connection | Butt Welded |
| Material Grade | SS316 Stainless Steel |
| Pressure Rating | 1000 PSI |
| Bore Type | Full Bore / Full Port |
| Seat Material | PTFE |
| Stem Design | Blow-Out Proof Stem |
| Operation Type | Manual Lever Operated |
| Flow Direction | Bidirectional |
| Media Compatibility | Water, Oil, Gas, Chemicals |
| Temperature Range | -20°C to +150°C |
| Installation Type | Inline Pipeline Mounting |
| Application | Industrial Process Control |
| Suitable Industries | Oil & Gas, Chemical, Water Treatment |
| Corrosion Resistance | High |
| Sealing Type | Soft Seated |
| Operation | Quarter Turn |
| Country of Manufacture | Industrial Grade Imported Valve |
